Outdoor Geology Lab Tour: Castle Hayne Limestone

Castle Hayne Limestone from Castle Hayne, North Carolina sign

Rock type
Sedimentary

Description
A large white rock filled with large seashells.

Figure 1: Castle Hayne limestone boulder at Northern Wake Campus.

Figure 1: Castle Hayne limestone boulder at Scott Northern Wake Campus


Figure 2: Castle Hayne limestone boulder at Southern Wake (Main) Campus.

Figure 2: Castle Hayne limestone boulder at Southern Wake Campus


Unique features
The main features in this boulder are shells of all sizes embedded in calcite mud. Some of the original shells are still present, but most of the shells are only impressions left behind when the original shell material dissolved away. If you look closely, you might be able to see that the shells are laid down in layers.

Figure 3: The surface of the Castle Hayne limestone showing various shells embedded in mud.

Figure 3: The surface of the Castle Hayne limestone showing various shells embedded in mud. (Black ballpoint pen for scale)


Figure 4: Detail of an impression made in the mud by a ridged shell.

Figure 4: Detail of an impression made in the mud by a ridged shell


Figure 5: Detail of preserved shell material

Figure 5: Detail of preserved shell material, just to the right of the black ballpoint pen. You can also see more shell impressions and other pieces of shell.


Figure 6: Another detail image showing some of the other ways that shells are found in this rock: impressions, preserved shell material, cavities, etc.

Figure 6: Another detail image showing some of the other ways that shells are found in this rock: impressions, preserved shell material, cavities, etc.


How did it form?
Sedimentary rocks form when debris accumulates and then is cemented together. The Castle Hayne limestone formed when shelly ocean invertebrates died and their shells and other skeletons accumulated in mud found on the ocean floor. The shells and mud lithified over the course of many years as they were buried beneath more mud and shells.

How would a geologist figure out how it formed using rock characteristics?
Examining the rock, we can see complete shells of all sizes embedded in white calcite mud. Laboratory experiments have shown that mud settles only in very calm water, such as in the ocean deep below where the waves move. Because the larger shells are embedded in mud, it suggests that this rock formed in an area of the ocean near a reef (to provide the shells) but deep enough below the surface of the water for the waves to not have much effect on the sediments that are deposited there.

Additional experiments have shown that, when shells are moved by water over long distances, the shells roll and bump into each other, becoming chipped or broken as they move. The shells in the Castle Hayne limestone are almost all complete and are not broken or chipped. This suggests that the shells in this limestone were not transported any great distance before being deposited. This line of evidence supports the hypothesis that this rock formed in relatively still water below the depth where the water is moved by waves, near a reef.

Other interesting information
The Castle Hayne limestone quarry has produced an incredible amount of rock that has been crushed into gravel and sand for construction. In fact, rock from this quarry is so plentiful that it was used to pave Interstate 40 in North Carolina from the coast to the mountains, and the quarry is still producing stone.
